The strength of your fencing system can make the difference when it comes to protecting your high-level premises, valuable stock and key assets. The tight upper profile of ArmaMesh358 Mesh fencing system does all of this and far exceeds those expectations.


Each hard-wearing security mesh panel is fixed to galvanised steel square posts using a full length clamp bar system matched with strong through bolts. This ensures quick and easy installation around any perimeter and maintains a great line of defence against any potential intruders.

Each welded steel wire panel is fixed securely to the continuous unique steel post using non removable shear nuts, providing a fantastic outer perimeter for clients who need high level security.

ArmaMesh358 also conforms to BS 1722-14 for open mesh steel panel fences, giving added peace of mind to the schools, businesses and government departments who use it


Height: 1200mm/1800mm/2000mm/2100mm/2400mm/3000mm (Heights up to 5200mm are available please contact Gramm Barrier Systems for more information on post specifications)
Nominal Height: 1.2m/1.8m/2.0m/2.1m/2.4m/3.0m (Heights up to 5.2m are available please contact CLD Fencing Systems for more information on post specifications
Mesh & Wire: 76.2 x 12.5 mm mesh; 4 mm wire, high aluminium content galvanised and polyester powder-coated to minimum 80 microns
Posts: 60 x 60 mm SHS, galvanised after manufacture and polyester powder-coated with 30 x 5mm full length clamp bar galvanised and polyester powder-coated to match fencing. (1200mm – 2400mm Panels ONLY)

80 x 40 mm RHS, galvanised after manufacture and polyester powder-coated with 30 x 5mm full length clamp bar galvanised and polyester powder-coated to match fencing. (3000mm Panels ONLY)

Fixings: M8 cup square bolt with permacone nut, galvanised.
Set Posts: Set posts in holes 300 mm diameter x 800** mm deep, filled not less than half the depth with concrete, as clause 620.
Maximum Posts Centres: 2440mm
Bottom of Fencing to Be: approx. 50 mm above final ground level or 300mm Ground Bury.
Other Requirements: PPC Colour Green RAL 6005. A full range of RAL Colours are available from Gramm Barrier Systems including marine grade and metallics.

Foundation types

Gramms ArmaMesh358 mesh fencing system can be either set into concrete foundations or bolted down to individual concrete pads or a continuous concrete strip/pad.

Fixing methods

a) Galvanised steel or PPC posts with baseplates can be fixed to concrete surfaces using chemfix resin anchors or cast in cradles.
b) Steel posts can be set into augered or bucket dug concrete foundations.
